TurboHD DVR up to 4K / 8MP Recording / 32 TVI channels + 8 IP channels / 4 Hard Drive slots / 4 audio In / Alarm I/O / Video analytics

Video/Audio Input

• Video input: 32 Channels
• Video Compression: H.265+/H.265/H.264+/H.264
• Analog and HD-TVI video input: 32-ch, BNC interface (1.0Vp-p, 75 Ω)connection
• Supported camera types:
  • Support HDTVI input: 5MP, 3MP, 1080p/30Hz, 720p/30Hz, 720p/60Hz
  • Support AHD input: 5MP, 4MP, 1080p/30Hz, 720p/30Hz
  • Support CVI input: 1080p25, 1080p30, 720p25, 720p30
  • Support CVBS input
• IP Video Input: 8-ch(up to 40ch) Up to 8MP resolution
• Audio Compression: G.711u
• Audio Input Interface: 4-ch, RCA (2.0 Vp-p, 1 KΩ)
• Two-way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)

Video/Audio Output

• CVBS Output: 1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480
• HDMI2 Output: 1-ch, 4K(3840 × 2160)/30Hz, 2K(2560×1440)/60Hz, 1920×1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• HDMI/VGA Output: 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
• Recording resolution: 5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
• Frame Rate:
  • Main stream: [email protected]; [email protected]; [email protected]; 1080p/ 720p/ WD1/ 4CIF/ VGA/ [email protected]
  • Sub-stream: WD1/4CIF/[email protected]/30fps
• Video Bit Rate: 32 Kbps-6 Mbps
• Stream Type: Video/Video&Audio
• Two-way Audio: 1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input)
• Audio Output: 1-ch RCA(Linear, 1kΩ)
• Dual Stream: Support
• Playback Resolution: 5MP/4MP/3MP/1080p/720p/VGA/WD1/4CIF/CIF
• Synchronous Playback: 16-ch

• Network protocols: TCP/IP, PPPoE, DHCP, Guarding Vision Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF

• Interface Type: 4 SATA Interfaces
• Capacity: Up to 8 TB capacity for each disk
• e-SATA Interface: 1 eSATA interface

• Network Interface: 2; 10M / 100M / 1000M self-adaptive Ethernet interfaces
• Serial Interface: 1 RS-232 serial interface, 1 RS-485 serial interface, full-duplex,1 RS-485 keyboard interface
• Alarm Input: 16-ch
• Alarm Output: 4-ch

• Power Supply: 100 to 240 VAC
• Consumption: ≤ 74W (without hard disks)
• Working Temperature: -10 ºC to +55 ºC (+14 ºF to +131 ºF)
• Working Humidity: 10% to 90%
• Dimensions: 440 × 390 × 70 mm (17.3 × 15.4 × 2.8 inch)
• Weight: ≤ 7 kg (15.4 lb)

3 Years Warranty
