DETECTOR INALAMBRICO DE INUNDACIÓN SERIE FORCE

DFL - Wireless Flood Detector

The DFL is a wireless flood detector with FastLink technology, designed for PIMA alarm systems. FastLink communication is encrypted using 128-bit AES encryption to provide a high level of security.

To use the DFL requires the prior installation of a wireless receiver.

The DFL has a modern design and runs on batteries. It can detect the presence of water and other liquids, and wirelessly transmit an alarm event to the control panel. The detector must be placed in a location where water can seep or accumulate, such as houses, commercial facilities, basements, and boats. The transmitter should be mounted in a high location and the sensor should be placed where it is likely to come into contact with the leak or flood.

The DFL reports low battery status and has a tamper switch that alerts when the unit opens or is removed from its installation location. The DFL transmits a test event every 15 minutes. The LED turns on in the event of an alarm, sabotage, and when the battery is low.

For information on how to register (enroll) the device, refer to the alarm system installation guide.

Technical specifications

-Frequencies (MHz):

-DFL143: 433.92

-DFL186: 868.35

-Batteries: 2X 1.5V, AAA, Alkaline

-Battery life: Up to 5 years (in typical use)

-Dimensions: 8.5 X 3.5 X 1.4cm

- Sensor cable length: 2m

-Weight: 70gr

-Complies with CE regulations

-Operating temperatures: from -10 to +55 ° C

-Humidity (Max.): 93% R.H., No condensation

Package content

-DFL detector

-2 Batteries

-Screws and mounting tapes

-This guide
