Osciloscopio Análogo TENMA compacto de Mesa, 2 Canales, 30 MHz.

    ​Two Channel Analog Oscilloscope, 30 MHz, Compact Bench Type.

• Bandwidth: 30 MHz
• Sample rate: 250 MS/s (optional 500 MS/s)
• Rise time: ≤ 11 ns
• Horizontal Scale(S/div): 5ns/div - 100s/div, step by1- 2- 5
• Display: 8" Colored LCD, 800 x 600 pixels, 65536 colors.
• Channel: 2 + 1 (External)
• Record length: Max 10K
• Input coupling: DC, AC , Ground
• Input impedance: 1 MΩ ± 2%, in parallel with 10 pF ± 5 pF
• Max. input voltage: 400 V (PK-PK) (DC + AC PK-PK)
• DC gain accuracy: ± 3%
• Vertical sensitivity: 5 mV/div – 5 V/div
• Trigger type: Edge, Video, Slope, Pulse, Alternate
• Trigger mode: Auto, Normal, Single
• Line/field frequency (Video): Support standard NTSC, PAL and SECAM broadcast                                              systems
• Automatic measurement: Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms,                                               Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time,                                         Delay A→B , Delay A→B , +Width, -Width, +Duty, -Duty.
• Waveform Math: ＋, －, ×, ÷, FFT
• Waveform storage: 15 waveforms
• Communication interface: USB 2.0, USB for file storage; LAN port;
• Power supply: 100 – 240 VAC, 50/60 Hz, CAT Ⅱ.

     *Ask for delivery time.
