PowerEdge R330 Server / Intel Xeon E3-1230 / 8GB RAM / 1 TB / Without OS

Accelerate application performance in SMB and Remote Office/Branch Office

Drive applications faster while providing room for future growth with the latest Intel® processors, DDR4 memory and PCIe Gen3 I/O.

• Drive greater memory performance and expand capacity up to 64GB through time with 4 x DIMM slots and enhanced DDR4 memory, offering 50% faster clock speed than previous-generation DDR3 which is 12.5% faster than the initial 2133 MT/s implementation of DDR4.*
• Boost data throughput with 2 x PCIe Gen 3.0 slots driving 2x data throughput compared to Generation 2.0.
• Drive 2x IOPS performance with the PowerEdge PERC9 RAID Controller, compared to previous-generation PowerEdge R320 equipped with PERC8.*
• Ensure fast response times with the latest quad core Intel® Xeon® E3-1200 v6 product family, as well as flexible dual core processor options including Intel Pentium ®, Intel Core i3 ®, or Intel Celeron ®.

Discover greater versatility

• Harness data growth with up to 4 x internal 3.5" cabled or hot plug HDD or 8 x 2.5" hot plug HDD.
• Enhance storage options with up to two optional 1.8" SSD drives to accelerate system boot/reboot time.
• Adapt to changing workload conditions with a virtualization-ready server supporting Citrix® ZenServer®, Microsoft Hyper -V, VMware® vSphere ESXi, and Red Hat® Enterprise Virtualization.

Maximize operational efficiency

• Deploy rapidly and turn the server over for productive work sooner with Dell OpenManage systems management solutions.
• Easily monitor system health and behavior with a simple, intuitive Dell OpenManage Essentials console.
• Save IT administrator time by automating firmware updates — up to 92% reduction in firmware update time using Repository Manager auto-updates compared to manual updates.*

Processor (not included)

• Intel® Xeon® processor E3-1200 v6 product family

Operating system

• Microsoft® Windows Server® 2012
• Microsoft Windows Server 2012 R2, x64
• Microsoft® Windows Server® 2016
• Red Hat® Enterprise Linux®
• VMware Vsphere® ESXi®
• SUSE® Linux Enterprise Server®

Memory

• Architecture: Up to 2400MT/s DDR4 DIMMs
• Memory type: UDIMMs
• Memory module sockets: 4
• Maximum RAM: Up to 64GB

Dimensions

• Width: 17.08 in / 434 mm
• Height: 1.68 in / 42.80 mm
• Depth: 24.60 in / 625 mm

Form factor

• 1U rack server

Power

• Up to 2 x 350W hot-plug redundant power supplies

RAID Controllers

• Internal controllers RAID: PERC S130, PERC H330, PERC H730, PERC H830

Chipset

• Intel C236

Storage

• 2.5" SATA SSDs
• 2.5" SATA 7.2k
• 2.5" SAS 15k HDDs
• 2.5" nearline SAS 7.2k
• 2.5" SAS 10K HDDs
• 3.5" Enterprise SATA 7.2k HDDs
• 3.5" nearline SAS 7.2k HDDs

Includes 1 3.5" SATA 7.2K HDD 1TB 6 Gbps

Slots

• 2 x PCIe 3.0 slots + 1 slot for internal storage

Network controller

• 2 x 1 GbE
