The ET-1004GP-2G provides 4-port 10/100/1000Mbps IEEE 802.3af/at Power over Ethernet with a total of 60 or 120 watts of PoE budget, which is an ideal solution to fulfill the demand of sufficient PoE power for network applications. It is able to drive 4 IEEE 802.3af/at compliant powered devices.

The ET-1004GP-2G  is an ideal solution for securing IP surveillance infrastructure. It provides both 802.3af/at PoE functions along with 4 x 10/100/1000Base-TX ports featuring 15.4-watt 802.3af/30.8-watt 802.3at PoE in RJ-45 interfaces and extra 2 x 10/100/1000Mbps UPLINK RJ-45 ports to keep a cascade connection with another switch or NVR. For instance, one ET-1004GP-2G can be combined with one 4-Channel NVR and four PoE IP cameras as a kit for the administrators to centrally and efficiently manage the surveillance system in the local LAN and the remote site via Internet.

The ET-1004GP-2G RJ-45 interfaces support 10/100/1000Mbps Auto-Negotiation at downlink port from 1 to 4 and uplink port from 1 to 2 for optimal speed detection through RJ-45 Category 6, 5e or 5 cables. It also supports standard Auto-MDI/MDI-X that can detect the type of connection to any Ethernet device without requiring special straight or crossover cables.
Manageable switch with 4 ports at 1000 Mbps and 2 ports uplink


Applications:

• Security monitoring system
• Multimedia network teaching system
• Medical monitoring display system
• Industrial automation control system
• Banking, securities and financial information system
• Remote monitoring of the network server
• Security of department stores
• Security in casinos
• Hospitals, Airports and banks
• School campuses

Physical Ports:

• 4 ports of 10/100/1000 Mbps + 2 port Up-link
• End-Span method
• Dimensions:
• Weight: 425 g

4/8-Port Gigabit
PoE Switch

ET-1004GP-2G/ ET-1008GP-2G

---

Advantages

More Voltage

Supports 48V-56V DC power to PoE powered devices.

More Power

High power budget up to 120W or 265W (AC) for 8 port switch.

More Watts

AF/AT Get 30W on each port.

More Bandwidth

Get 1 Gigabit bandwith, SFP fiber ports for "UpLink".

More Safe

High surge protection Level: 6KV

Power Supply Mode

Power adaptor or internal power supply for corresponding model.

---

Features

• Automatic indentify standard PD, intelligent Power Supply.

• Restart function helps master IC reset wholly.

• Frame loss rate: 0%.

• No electric sparks when plug and play.

• Energy-efficient Ethernet function.

• Unique ESD protection design.

• Operating temperature: 0-55't.

---

Application Diagram
